Specifications
Form factor M.2 2280
Interface NVMe™ PCIe Gen 3.0 x 4 Lanes
Capacities2 500GB
NAND 3D
Encrypted XTS-AES 256-bit Encryption
Sequential Read/Write1
500GB – up to 2,200/2,000MB/s
Random 4K Read/Write1
500GB – up to 180,000/200,000 IOPS
Total Bytes Written (TBW)3
500GB – 350TBW
Power Consumption .0032W Idle / .08W Avg / 1.7W (MAX) Read / 4.5W (MAX) Write
Storage temperature -40°C ~ 85°C
Operating temperature 0°C ~ 70°C
Dimensions 80mm x 22mm x 3.5mm
Weight
500GB – 6.8g
Vibration operating 2.17G Peak (7-800Hz)
Vibration non-operating 2.17G Peak (7-800Hz)
MTBF 2,000,000
Warranty/support4
Limited 5-year warranty with free technical support
